Fully Automatic 6-Lane Linear Sauce Packing Machine

High-Speed Multi-Lane Stick Pack & Sachet Packaging Machine with Servo Piston Pumps for Hot Pot Base, Ketchup, Chili Oil, and High-Viscosity Fluids

Target Industries & Applications | Who We Serve

• Tier-1 Condiment & Sauce Manufacturers: Engineered for industrial-scale 24/7 production lines requiring high-speed, multi-lane stick packaging for hot pot base, tomato ketchup, chili oil, peanut butter, honey, and viscous liquid seasonings.

• Global Food Service & Instant Food Contract Packers: Optimized for handling single-serve portion packs (e.g., hot pot seasoning packets, instant noodle sauce sachets, take-out condiment packs), ensuring hermetic seals and zero oil leakage.

• Integrated End-of-Line (EOL) Automation: Serves as the primary high-yield packaging station, capable of seamless synchronization with automatic labeling machines, checkweighers, batch inkjet coders, and real-time cartoning systems.

• Moisture-Proofing, Leak Prevention & Extended Shelf Life: Delivers secure 3-side or 4-side fin seals with high-barrier plastic/foil composite films, preventing oil or liquid separation and maximizing product freshness and shelf appeal.

Technical Specifications & Engineering Highlights

• High-Precision 6-Lane Servo Piston Filling Engine: Equipped with independent servo-driven piston pumps and anti-drip cut-off nozzles, ensuring high-accuracy volumetric dosing across all 6 lanes at stable outputs up to 150–240+ sachets/minute.

• Advanced Multi-Lane Film Pulling & Tracking System: Features intelligent photoelectric color mark tracking (PLC controlled) and auto-tension film roll unwinding, guaranteeing precise cutting registration and minimal film waste.

• Robust GMP-Compliant Stainless Steel Construction: Built using SUS304/SUS316 food-grade stainless steel, featuring an ergonomic, wash-down-friendly design that meets strict food hygiene and safety standards.

• Modular "Quick-Change" Forming Dies & Easy Cleaning: Includes tool-less format changeover for different sachet widths and CIP (Clean-in-Place) compatible liquid hoppers for rapid sanitization.

• Global Open-Architecture Infrastructure (MOQ = 1): Built for 24/7 continuous industrial operation. Minimum Order Quantity: 1 Unit.

Overcoming Plant Vulnerabilities | Solutions for Manufacturers

Pain Point 1: Sauce Dripping, Sealing Edge Contamination, and Oil Leakage in High-Speed Multi-Lane Sachet Production

• The Dession Solution: Our proprietary anti-drip suck-back piston design and independent PID digital temperature control heating jaws guarantee clean, grease-free, hermetic heat seals across all 6 lanes without film burning or pinholes.

Pain Point 2: Inconsistent Filling Volumes Across Multiple Lanes and High Film Wastage Due to Misalignment

• The Dession Solution: Integrated with multi-axis servo independent drive and high-precision photoelectric sensors, ensuring uniform filling weight per lane and zero tracking drift during high-speed operation.
